[Technical Classroom] UniMAT Internet of Things Application Course (1) - Introduction to Internet of Things Software and Hardware

In order to help UniMAT customers use IoT products more conveniently, a series of articles on IoT application courses are specially launched . The articles will comprehensively introduce the software and hardware, operation methods, related configurations, typical applications, common problems and other knowledge of UniMAT IoT. After reading the full text, you can have a comprehensive understanding of the Internet of Things, and achieve more with less for the application of the Internet of Things.

This issue brings you the introduction of Edimensional IoT software and hardware.

1. Special instructions

1. After the HMI enters the configuration project, press and hold the upper left corner for 5 seconds to enter the system settings

2. HMI/gateway default IP: 192.168.1.100,

UN PLC default IP: 192.168.1.254,

X PLC default IP: 192.168.1.254

3. After the AnyAccess device is registered, please bind the corresponding IoT card.

4. For IoT touch screen, the link configuration in Uniface and AnyAccess should be consistent.

5. The software on the official website may have been updated. To obtain the latest software, please visit the official website of UniMAT.

6. The location of the buttons shown in the text of the new board software may have changed, please refer to the new version.

2. Related software

01HMI programming software

In order to obtain the latest version in time, please go to the official website to download the latest version of the software. The link in the article either does not exist, or the version has been updated.

Official website download address:

https://www.unimatautomation.com/pages/download

It is used for HMI screen configuration and firmware update. For the IoT screen, you can configure real-time data, historical data, alarm, script and other functions in Uniface first, export through configuration, and import from AnyAccess.

download link:

https://drive.google.com/file/d/1GYEc7cgwIMrZ4J4UjWNhZWSD8QFsrYn2/view?usp=sharing

02Device management platform

The device management platform and Anyaccess software may be updated, and the location of the relevant icons may be inconsistent with this article, and the actual situation shall prevail.

A. Software version: AnyAccess_X64 or AnyAccess_X86

Equipment management platform, install corresponding software according to different computer systems. For configuration of real-time data, historical data, alarms, scripts, etc.

download link:

AnyAccess_X86: Device management platform for 32-bit OS

https://drive.google.com/file/d/1BezR4-vCxYVd3jBJJGU5-rcFN-SySguY/view?usp=sharing

AnyAccess_X64: Device management platform for 64-bit OS

https://drive.google.com/file/d/1RJhuVEvxnqzwiWpFEtnajVILyyH2k8lq/view?usp=sharing

B. Web version:

Device management platform: https://www.gongyeyuniot.com/dev/login

Overseas version: http://www.deviot.cc/dev/login

The web version of the device management platform cannot be downloaded remotely, and other functions are the same as AnyAccess.

03 Cloud configuration platform

It is used for device cloud configuration, large-screen display, report design, and permission setting.

Address: http://xxx.deviot.cn xxx is a second-level domain name. Before applying, you need to register an account with the device management platform.

Example: http://tsd.deviot.cn

Overseas version: http://xxx.deviot.cc/ xxx is a second-level domain name. Before applying, you need to register an account with the device management platform. It is recommended to register an account with an email address.

The address of the cloud configuration platform is the domain name applied for by "Applying for a Second-Level Domain Name".

3. About the account

Device management platform AnyAccess

Web version device management platform https://www.gongyeyuniot.com/dev/login

Cloud configuration platform http://xxx.deviot.cn/iotyun/login ,

UniMAT IoT Platform http://www.unimatiot.com/ywyun/login

Mobile APP, Industrial Equipment Cloud

The above platforms share one account.
